The Pinnacle Of Chain Technology
Ultra Strong
The ZZZ chain features a revolutionary new side plate profile that more effectively distributes the load onto the side plate. This innovative design gives the 530ZZZ chain an incredible 11,100lb. tensile strength without increasing weight(4.85 lbs. per 100 links).
Zero Stretch
EK’s proprietary Zero Stretch Technology (ZST) virtually eliminates initial chain stretch. No chain adjustment is needed in the first 1000km of use.
Chain | Pin | Roller | Plate Thickness | Tensile | Wear Life | Weight | Disp. | Standard Connecting Link |
Optional Connecting Link |
|||||
Dia. | Length | Dia. | Inner | Outer | Strength | Index | 100 links | Max cc's | ||||||
(mm) | (mm) | (mm) | (mm) | (mm) | (lbs.) | (kN) | Std. As 100 | (lbs.) | (kg) | Street | Dirt | |||
520ZZZ |
5.38 | 21.20 |
10.30 |
2.2 |
2.4 |
9,400 |
41.8 |
1,700 |
3.97 |
1.80 |
1,000 |
NA | MLJ | - |
525ZZZ | 5.38 | 23.60 | 10.30 | 2.4 | 2.6 | 10,300 | 45.8 | 1,700 | 4.52 | 2.05 | 1,100 | NA | MLJ | - |
530ZZZ | 5.38 | 25.40 | 10.30 | 2.4 | 2.6 | 11,000 | 48.9 | 1,700 | 4.85 | 2.20 | 1,400 | NA | MLJ | - |
The Ultimate Sport Bike Chain
In a direct comparison to all other premium chains, the EK ZVX easily surpasses every other brand with a tensile strength of 10,560 lbs(530ZVX2).
Chain | Pin | Roller | Plate Thickness | Tensile | Wear Life | Weight | Disp. | Standard Connecting Link |
Optional Connecting Link |
|||||
Dia. | Length | Dia. | Inner | Outer | Strength | Index | 100 links | Max cc's | ||||||
(mm) | (mm) | (mm) | (mm) | (mm) | (lbs.) | (kN) | Std. As 100 | (lbs.) | (kg) | Street | Dirt | |||
428ZVX |
4.50 |
20.80 |
8.51 |
2.0 |
2.0 |
6,600 |
29.5 |
1,500 | 2.54 |
1.15 |
400 |
250 | MLJ | SKJ |
525ZVX2 | 5.38 | 21.50 | 10.30 | 2.2 | 2.2 | 9,000 | 40.0 | 1,500 | 3.99 | 1.81 | 1,000 | NA | MLJ | - |
520ZZZ | 5.38 | 23.80 | 10.30 | 2.4 | 2.6 | 10,300 | 45.8 | 1,500 | 4.73 | 2.15 | 1,200 | NA | MLJ | - |
530ZVX2 | 5.38 | 25.80 | 10.30 | 2.4 | 2.6 | 10,560 | 46.9 | 1,500 | 4.89 | 2.22 | 1,400 | NA | MLJ | - |
532ZVX | 5.64 | 25.40 | 11.10 | 2.6 | 2.4 | 10,560 | 46.9 | 1,500 | 5.06 | 2.31 | 1,300 | NA | MLJ | SLJ |
Our Supreme Quadra-X Ring Chains,The Ideal OE Replacement
EK’s MVXZ Quadra-X Ring chain is the ideal replacement chain for any 600 to 1000cc street bike. Features like lightening holes in the sideplates, large-diameter pins, and friction-reducing Quadra-X Rings help ensure high-performance and from 1 1/2 to 2 times increased wear life when compared to a standard O-Ring chain.
Chain | Pin | Roller | Plate Thickness | Tensile | Wear Life | Weight | Disp. | Standard Connecting Link |
Optional Connecting Link |
|||||
Dia. | Length | Dia. | Inner | Outer | Strength | Index | 100 links | Max cc's | ||||||
(mm) | (mm) | (mm) | (mm) | (mm) | (lbs.) | (kN) | Std. As 100 | (lbs.) | (kg) | Street | Dirt | |||
520MVXZ |
5.38 | 21.50 |
10.20 |
2.2 | 2.2 | 9,000 |
40.0 |
1,500 | 3.99 |
1.81 |
1,000 | 750 | MLJ | SKJ,SLJ |
525MVXZ | 5.38 | 23.00 | 10.20 | 2.2 | 2.2 | 9,300 | 41.3 | 1,500 | 4.21 | 1.91 | 1,000 | 750 | MLJ | SLJ |
530MVXZ | 5.38 | 24.60 | 10.30 | 2.2 | 2.2 | 9,300 | 41.3 | 1,500 | 4.46 | 2.02 | 1,000 | 750 | MLJ | SLJ |
The Ultimate Sport Bike Chain
The SRX series chains are an excellent value for any street machine. The SRX chains feature lightening holes, reduced friction and Quadra X-Ring design which increases chain life from 1 1/2 to 2 times longer than a standard O-Ring chain.
Chain | Pin | Roller | Plate Thickness | Tensile | Wear Life | Weight | Disp. | Standard Connecting Link |
Optional Connecting Link |
|||||
Dia. | Length | Dia. | Inner | Outer | Strength | Index | 100 links | Max cc's | ||||||
(mm) | (mm) | (mm) | (mm) | (mm) | (lbs.) | (kN) | Std. As 100 | (lbs.) | (kg) | Street | Dirt | |||
420SRX |
3.96 |
16.80 |
7.77 |
1.5 |
1.5 |
4,600 |
20.5 |
1,200 |
1.69 |
0.77 |
150 |
150 | SKJ |
MLJ |
520SRXL | 5.24 | 20.10 | 10.16 | 2.0 | 2.0 | 8,000 | 35.6 | 1,200 |
3.50 | 1.59 | 650 | 650 | MLJ | SKJ,SLJ |
520SRX | 5.38 | 21.50 | 10.16 | 2.2 | 2.2 | 8,500 | 37.8 | 1,200 |
3.70 | 1.68 | 750 | 750 | MLJ | SKJ,SLJ |
525SRX | 5.38 | 23.00 | 10.20 | 2.2 | 2.2 | 8,800 | 39.1 | 1,200 |
3.91 | 1.77 | 900 | 750 | MLJ | SLJ |
530SRX | 5.38 | 25.40 | 10.20 | 2.4 | 2.4 | 9,400 | 41.8 | 1,200 |
4.80 | 2.17 | 1,000 | 750 | MLJ | SLJ |
The 520SRXL is a slim version of the 520SRX made specifically for smaller or mid sized street motorcycles
